liten

Arc Carousel

A carousel that fans its cards across the top of a circle, the active card rests at the apex, crisp and upright, while its neighbours curve down each slope and recede.

Layered mountain ridges at dawn
Card 3 of 6: Layered mountain ridges at dawn

A freestanding carousel that stages its cards on the top of a large circle instead of a flat strip. No panel frames it: the cards hang in open space over a soft contact shadow that grounds the fan. The active card rests at the apex, upright and crisp on the focal plane; its neighbours curve down each slope, rotating with the arc's tangent while they fall back, dim, and blur with depth. One spring drives every way of moving: arrows, keys, drag, and clicking a card all retarget the same fractional index, so a flick mid-glide keeps its momentum instead of restarting. On a fine pointer the whole dome leans a few degrees toward the cursor. Built with Motion.

Drag the arc and flick: a quick swipe advances regardless of distance. Click any card on a slope to rotate it up to the apex.

Installation

Complete the shared Setup first, then add Motion.

Terminal
bun add motion

Copy the component into components/ui/arc-carousel.tsx.

components/ui/arc-carousel.tsx
'use client';import * as React from 'react';import {  motion,  useMotionTemplate,  useMotionValue,  useReducedMotion,  useSpring,  useTransform,  type MotionValue,} from 'motion/react';import { ChevronLeft, ChevronRight } from 'lucide-react';import { cn } from '@/lib/cn';const EASE_OUT = [0.23, 1, 0.32, 1] as const;const GLIDE = { stiffness: 170, damping: 26, mass: 1 } as const;const TILT = { stiffness: 110, damping: 16 } as const;const EASE_CSS = '[transition-timing-function:cubic-bezier(0.23,1,0.32,1)]';const clamp = (v: number, min: number, max: number) =>  Math.min(max, Math.max(min, v));const DEG = Math.PI / 180;export type ArcCarouselItem = {  src: string;  alt: string;  label?: string;};export type ArcCarouselProps = {  items: ArcCarouselItem[];  defaultIndex?: number;  accent?: string;  ratio?: string;  spread?: number;  radius?: number;  label?: string;  className?: string;};export function ArcCarousel({  items,  defaultIndex = 0,  accent = '#f0883e',  ratio = '4 / 3',  spread = 20,  radius = 640,  label = 'Arc carousel',  className,}: ArcCarouselProps) {  const reduce = useReducedMotion();  const count = items.length;  const last = count - 1;  const [active, setActive] = React.useState(() =>    clamp(defaultIndex, 0, Math.max(0, last)),  );  const target = useMotionValue(active);  const progress = useSpring(target, GLIDE);  const tiltX = useSpring(0, TILT);  const tiltY = useSpring(0, TILT);  const sceneTransform = useMotionTemplate`rotateX(${tiltY}deg) rotateY(${tiltX}deg)`;  const [finePointer, setFinePointer] = React.useState(false);  React.useEffect(() => {    const mq = window.matchMedia('(hover: hover) and (pointer: fine)');    const update = () => setFinePointer(mq.matches);    update();    mq.addEventListener('change', update);    return () => mq.removeEventListener('change', update);  }, []);  const stageRef = React.useRef<HTMLDivElement>(null);  const drag = React.useRef<{    id: number;    startX: number;    base: number;    lastX: number;    lastT: number;    velocity: number;    moved: number;  } | null>(null);  const suppressClick = React.useRef(false);  const goTo = React.useCallback(    (i: number) => {      const next = clamp(i, 0, last);      setActive(next);      target.set(next);    },    [last, target],  );  const onPointerDown = (e: React.PointerEvent) => {    if (drag.current) return;    if (e.pointerType === 'mouse' && e.button !== 0) return;    drag.current = {      id: e.pointerId,      startX: e.clientX,      base: target.get(),      lastX: e.clientX,      lastT: e.timeStamp,      velocity: 0,      moved: 0,    };    suppressClick.current = false;    stageRef.current?.setPointerCapture(e.pointerId);  };  const onPointerMove = (e: React.PointerEvent) => {    if (finePointer && !reduce && !drag.current) {      const rect = stageRef.current?.getBoundingClientRect();      if (rect) {        const nx = ((e.clientX - rect.left) / rect.width) * 2 - 1;        const ny = ((e.clientY - rect.top) / rect.height) * 2 - 1;        tiltX.set(nx * 5);        tiltY.set(ny * -3);      }    }    const d = drag.current;    if (!d || e.pointerId !== d.id) return;    const dx = e.clientX - d.startX;    d.moved = Math.max(d.moved, Math.abs(dx));    if (d.moved > 6) suppressClick.current = true;    const dt = e.timeStamp - d.lastT;    if (dt > 0) d.velocity = (e.clientX - d.lastX) / dt;    d.lastX = e.clientX;    d.lastT = e.timeStamp;    const step = (stageRef.current?.offsetWidth ?? 640) * 0.42;    let raw = d.base - dx / step;    if (raw < 0) raw *= 0.35;    else if (raw > last) raw = last + (raw - last) * 0.35;    target.jump(raw);  };  const endDrag = (e: React.PointerEvent) => {    const d = drag.current;    if (!d || e.pointerId !== d.id) return;    drag.current = null;    stageRef.current?.releasePointerCapture(d.id);    const current = target.get();    let next: number;    if (Math.abs(d.velocity) > 0.35 && d.moved > 12) {      next = d.velocity < 0 ? Math.ceil(current) : Math.floor(current);    } else {      next = Math.round(current);    }    goTo(next);  };  const onPointerLeave = () => {    tiltX.set(0);    tiltY.set(0);  };  const onKeyDown = (e: React.KeyboardEvent) => {    if (e.key === 'ArrowRight') {      e.preventDefault();      goTo(active + 1);    } else if (e.key === 'ArrowLeft') {      e.preventDefault();      goTo(active - 1);    } else if (e.key === 'Home') {      e.preventDefault();      goTo(0);    } else if (e.key === 'End') {      e.preventDefault();      goTo(last);    }  };  return (    <section      aria-roledescription="carousel"      aria-label={label}      style={{ '--arc-accent': accent } as React.CSSProperties}      className={cn(        'relative w-full max-w-[760px] text-neutral-900 dark:text-white',        className,      )}    >      <div        ref={stageRef}        role="group"        tabIndex={0}        aria-label={`Card ${active + 1} of ${count}`}        onPointerDown={onPointerDown}        onPointerMove={onPointerMove}        onPointerUp={endDrag}        onPointerCancel={endDrag}        onPointerLeave={onPointerLeave}        onKeyDown={onKeyDown}        className={cn(          'relative h-[360px] touch-pan-y select-none rounded-[18px]',          'cursor-grab active:cursor-grabbing',          'focus-visible:outline-none focus-visible:outline focus-visible:outline-2 focus-visible:outline-offset-4 focus-visible:[outline-color:var(--arc-accent)]',        )}        style={{ perspective: 1300 }}      >        <div          aria-hidden          className="pointer-events-none absolute top-[62%] left-1/2 h-14 w-[46%] -translate-x-1/2 rounded-[100%] bg-black/15 blur-2xl dark:bg-black/50"        />        <motion.div          style={{            transform: reduce ? undefined : sceneTransform,            transformStyle: 'preserve-3d',          }}          className="absolute inset-0 [mask-image:linear-gradient(to_right,transparent,black_4%,black_96%,transparent)]"        >          {items.map((item, i) => (            <ArcCard              key={i}              item={item}              index={i}              progress={progress}              ratio={ratio}              spread={spread}              radius={radius}              active={i === active}              reduce={!!reduce}              onSelect={() => {                if (!suppressClick.current) goTo(i);              }}            />          ))}        </motion.div>      </div>      <div className="mt-1 flex items-center justify-center gap-5">        <ArcArrow          dir="prev"          disabled={active <= 0}          onClick={() => goTo(active - 1)}        />        <div          aria-hidden          className="flex items-baseline gap-1 text-[13px] font-medium tabular-nums tracking-[-0.01em]"        >          <span style={{ color: 'var(--arc-accent)' }}>            {String(active + 1).padStart(2, '0')}          </span>          <span className="text-neutral-400 dark:text-neutral-600">/</span>          <span className="text-neutral-400 dark:text-neutral-500">            {String(count).padStart(2, '0')}          </span>        </div>        <ArcArrow          dir="next"          disabled={active >= last}          onClick={() => goTo(active + 1)}        />      </div>      <span aria-live="polite" className="sr-only">        Card {active + 1} of {count}: {items[active]?.alt}      </span>    </section>  );}function ArcArrow({  dir,  disabled,  onClick,}: {  dir: 'prev' | 'next';  disabled: boolean;  onClick: () => void;}) {  const Chevron = dir === 'prev' ? ChevronLeft : ChevronRight;  return (    <button      type="button"      aria-label={dir === 'prev' ? 'Previous card' : 'Next card'}      disabled={disabled}      onPointerDown={(e) => e.stopPropagation()}      onClick={onClick}      className={cn(        'bloom-edge group grid size-9 shrink-0 place-items-center rounded-full',        'bg-gradient-to-b from-white to-[#f1f1f2] dark:from-[#272727] dark:to-[#1c1c1c]',        'shadow-[inset_0_1px_0_0_rgba(255,255,255,0.9),0_1px_2px_0_rgba(0,0,0,0.08),0_6px_16px_-8px_rgba(0,0,0,0.2)]',        'dark:shadow-[inset_0_1px_0_0_rgba(255,255,255,0.08),0_1px_2px_0_rgba(0,0,0,0.5),0_8px_20px_-10px_rgba(0,0,0,0.7)]',        `transition-[transform,opacity] duration-150 ${EASE_CSS}`,        'hover:-translate-y-px active:scale-[0.94] active:translate-y-0',        'motion-reduce:hover:translate-y-0 motion-reduce:active:scale-100',        'disabled:pointer-events-none disabled:opacity-35',        'focus-visible:outline-none focus-visible:outline focus-visible:outline-2 focus-visible:outline-offset-2 focus-visible:[outline-color:var(--arc-accent)]',      )}    >      <Chevron        size={17}        strokeWidth={2}        aria-hidden        className={cn(          'text-neutral-600 dark:text-neutral-300',          `transition-transform duration-200 ${EASE_CSS}`,          dir === 'prev'            ? 'group-hover:-translate-x-0.5'            : 'group-hover:translate-x-0.5',          'motion-reduce:transition-none motion-reduce:group-hover:translate-x-0',        )}      />    </button>  );}function ArcCard({  item,  index,  progress,  ratio,  spread,  radius,  active,  reduce,  onSelect,}: {  item: ArcCarouselItem;  index: number;  progress: MotionValue<number>;  ratio: string;  spread: number;  radius: number;  active: boolean;  reduce: boolean;  onSelect: () => void;}) {  const d = useTransform(progress, (v) => index - v);  const transform = useTransform(d, (t) => {    if (reduce) return 'translate(-50%, -50%)';    const c = clamp(t, -4, 4);    const a = Math.abs(c);    const phi = c * spread * DEG;    const x = radius * Math.sin(phi);    const y = radius * (1 - Math.cos(phi)) * 0.78;    const z = -a * 130;    const scale = 1 - Math.min(a * 0.04, 0.28);    const rot = c * spread;    return `translate(-50%, -50%) translate3d(${x.toFixed(2)}px, ${y.toFixed(2)}px, ${z.toFixed(2)}px) rotateZ(${rot.toFixed(2)}deg) scale(${scale.toFixed(3)})`;  });  const opacity = useTransform(d, (t) => {    const a = Math.abs(t);    if (reduce) return a < 0.5 ? 1 : 0;    if (a <= 1) return 1;    return Math.max(0, 1 - (a - 1) * 0.4);  });  const filter = useTransform(d, (t) =>    reduce ? 'none' : `blur(${Math.min(Math.abs(t) * 1.3, 4.5).toFixed(2)}px)`,  );  const zIndex = useTransform(d, (t) => 100 - Math.round(Math.abs(t) * 10));  const pointerEvents = useTransform(d, (t) =>    Math.abs(t) > 3.2 ? ('none' as const) : ('auto' as const),  );  return (    <motion.div      aria-hidden={!active}      style={{        transform,        opacity,        filter,        zIndex,        pointerEvents,        aspectRatio: ratio,      }}      onClick={onSelect}      className={cn(        'absolute top-[38%] left-1/2 w-[min(42%,270px)] overflow-hidden rounded-[13px]',        'bloom-edge bg-neutral-200 dark:bg-[#242424]',        'shadow-[0_1px_2px_0_rgba(0,0,0,0.08),0_16px_34px_-14px_rgba(0,0,0,0.28)]',        'dark:shadow-[inset_0_1px_0_0_rgba(255,255,255,0.07),0_1px_2px_0_rgba(0,0,0,0.4),0_20px_48px_-14px_rgba(0,0,0,0.72)]',        !active && 'cursor-pointer',      )}    >      <img        src={item.src}        alt={active ? item.alt : ''}        draggable={false}        decoding="async"        className="pointer-events-none block size-full object-cover"      />      <span        aria-hidden        className="pointer-events-none absolute inset-0 rounded-[13px] bg-gradient-to-b from-white/12 to-transparent to-35% dark:from-white/[0.08]"      />      {item.label && (        <div          aria-hidden          className={cn(            'pointer-events-none absolute inset-x-0 bottom-0 flex items-end p-3 pt-10',            'bg-gradient-to-t from-black/60 via-black/15 to-transparent',            `transition-opacity duration-300 ${EASE_CSS}`,            active ? 'opacity-100' : 'opacity-0',          )}        >          <span className="truncate text-[12.5px] font-medium tracking-[-0.01em] text-white drop-shadow-[0_1px_3px_rgba(0,0,0,0.6)]">            {item.label}          </span>        </div>      )}      <span        aria-hidden        className={cn(          'pointer-events-none absolute inset-0 rounded-[13px] bg-black/20',          `transition-opacity duration-300 ${EASE_CSS}`,          active ? 'opacity-0' : 'opacity-100',        )}      />    </motion.div>  );}

Usage

Example.tsx
import { ArcCarousel } from '@/components/ui/arc-carousel';

export default function Example() {
  return (
    <ArcCarousel
      items={[
        { src: '/media/one.jpg', alt: 'Dunes at dusk', label: 'Evening Dunes' },
        { src: '/media/two.jpg', alt: 'Coastline from above', label: 'Coastline' },
        { src: '/media/three.jpg', alt: 'Ridges at dawn', label: 'Ridgelines' },
      ]}
    />
  );
}

Examples

spread sets the degrees between neighbouring cards and radius the curvature: a larger radius with a smaller spread flattens the dome into a gentle rise.

Dunes folding into soft evening light
Card 1 of 4: Dunes folding into soft evening light

Props

PropTypeDefaultDescription
items{ src: string; alt: string; label?: string }[]-The cards.
defaultIndexnumber0Card at the apex first.
accentstring"#f0883e"Focus ring and counter tint.
ratiostring"4 / 3"Aspect ratio of each card.
spreadnumber20Degrees between neighbouring cards along the arc.
radiusnumber640Radius of the arc in px; larger flattens the dome.
labelstring"Arc carousel"Accessible name for the carousel region.
classNamestring-Forwarded to the outer panel.
